Description

Fitment Information

• Chevy Silverado 2500/3500 HD (2020, 2021, 2022)

Specs & Features

• Sold individually
• Body: 2.0″ Impact extruded and CNC machined 6061-T6 clear anodized aluminum one-piece body resists rust over time
• Body Plating: Clear-anodized for a durable finish
• Reservoir: 2.0″ Smooth bore 6061-T6 Aluminum is hard anodized
• Components: Black-anodized, CNC-machined 6061-T6 billet aluminum
• Shaft: 5/8″ hard chrome plated heat-treated alloy steel
• Piston: Race-developed high-flow piston design
• Valving: Application specific valving to maximize performance
• Seals: Redundant sealing pack system main seal, wiper seal, scraper seal
• Bushings: Quiet nitrile rubber allows for increased suspension articulation
• Extended: 27.320
• Compressed: 16.700
• Travel: 10.620
• Top Mount: Eyelet
• Bottom Mount: Eyelet

Product Description

The aluminum bodied Performance Series 2.0 Reservoir smooth body shock delivers FOX’s industry leading and race dominating performance in an affordable, hassle-free bolt on package. Its heat reducing design includes a metal impacted clear anodized aluminum shock body that dissipates heat faster than a conventional steel body shock.

Its external reservoir allows for increase oil and nitrogen capacity while delivering a striking race look. The included black anodized reservoir mounting clamp and other components are CNC machined from 6061-T6 aluminum. The race developed high flow damping piston matched with application specific valving provides the Performance Series 2.0 Reservoir shock a predicable ride quality capable of handling the roughest road conditions.

Redline360 sells only genuine and authentic FOX products.
