Description

1989-1991 Honda Civic/CRX Sport Clutch Kit with Rigid 4-Pad Race Disc by ACT

HC4-SPR4 kit features a Sport pressure plate for a nice upgrade. ACT Sport pressure plates use exclusive diaphragm design to increase clamp load, reduce deflection and maximize clutch life. All diaphragms endure a four-stage, heat-treating process for unparalleled performance. ACT pressure plates have precision cover stampings to provide rigidity and consistency.

ACT’s 4-pad rigid race discs are made with high quality, ceramic friction materials. The chrome-moly hub is heat-treated for strength and durability. The lightweight, rigid design allows for quicker shifts and smooth, trouble-free service. With the 4-pad rigid race disc, engagement is harsher, but shifting is faster. The 4-pad rigid race disc is well-suited for the smaller disc sizes in smaller engines.

Features

• Feel: Light to moderate pedal effort, aggressive engagement, increased gear rattle
• Life: Moderate friction life, extended by ACT’s exclusive diaphragm design, rigid design may increase spline wear
• Quality: Carefully engineered, precisely assembled, accurately balanced, uses select ceramic friction materials for high heat tolerance and maximum performance
• Recommended Use: Recommended for race use only
• ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability

Benefits

• Torque Capacity (ft/lbs): 250
• Torque Capacity Over OE: 64%

Please Note: Recommended for race use only

Applications

• 1989 – 1991 Honda Civic 1.5L/1.6L
• 1989 – 1991 Honda CRX 1.5L/1.6L

What’s In The Box?

• 1 – 4 Pad Rigid Race Disc
• 1 – Sport Pressure Plate
• 1 – Pilot Bearing
• 1 – Release Bearing
• 1 – Alignment Tool

References

• Installation Instructions

Warranty

• ACT warrants all products to be free of defects in materials and workmanship for normal use and service for a period of one (1) year from retail purchase.
